Quartz Silica Wedge Depolarizer
Features and Advantages:
- No need for optical axis alignment
- Used to convert polarized light into non-polarized light
- Suitable for monochromatic light and wide-spectrum light sources
- Available in two types: cemented and optical bonded
- Better performance
PRODUCT
Detail
The quartz-silica wedge depolarizer is a common commercial design ,the angle between the two components is much smaller and only the first component is birefringent. The second component is made of fused silica, which has a very similar refractive index to quartz, but is not birefringent. The fast axis of the quartz element is generally at 45° to the wedge.
|
Common Specifications
|
|
|
Material
|
Quartz and Fused Silica
|
|
Wavelength range
|
220-1100nm,1100-2600nm
|
|
Parallelism
|
1 arcmin
|
|
Surface Quality
|
60-40
|
|
Flatness
|
λ/8@633nm
|
|
Peack Transmittance
|
92%（Uncoated）
|
|
Coating
|
Standard product is uncoated, custom made is available
|
|
Mount
|
Standard product is unmounted, custom made is available
|
Enlumen offers the following standard products for selection.
|
P/N
|
Sizes AXB(mm)
|
CA（mm）
|
Thickness(mm)
|
|
DQW10
|
10
|
9
|
5
|
|
DQW12
|
12.7
|
11.5
|
|
|
DQW15
|
15
|
13.5
|
|
|
DQW20
|
20
|
18.5
|
|
|
DQW25
|
25.4
|
22
|
